Motor Model | Working Voltage | No load | At maximum efficiency | At stall | ||||||
Rotation speed | Current | Rotation speed | Current | Torque | Power | Efficiency | Current | Torque | ||
r/min | A | r/min | A | mNm | W | % | A | mNm | ||
RS-770SHF-40103R | 12VDC | 3800 | 0.21 | 3384 | 1.68 | 37.0 | 13.11 | 65.03 | 13.49 | 338.0 |
RS-775SH-4537R | 12VDC | 5150 | 0.56 | 4378 | 3.18 | 57.3 | 26.29 | 69.00 | 18.00 | 382.5 |
