Motor Model | Working Voltage | No load | At maximum efficiency | At stall | ||||||
Rotation speed | Current | Rotation speed | Current | Torque | Power | Efficiency | Current | Torque | ||
r/min | A | r/min | A | mNm | W | % | A | mNm | ||
RS-560SHV-28126R | 12VDC | 3500 | 0.12 | 3035 | 0.75 | 20.3 | 6.46 | 71.70 | 4.90 | 153.0 |
RS-565PH-2595R | 24VDC | 4800 | 0.13 | 4128 | 0.8 | 31.9 | 13.77 | 71.90 | 4.90 | 227.5 |
